Remote Payload MonitoringGPRS Connectivity (Optional)
Payload-T GPRS Monitoring System
Track trips, loads, and overloads from anywhere. The Payload-T GPRS module stores up to 5000 weighments, syncs automatically to the server once a connection is available, and delivers online reports for every vehicle.
5000
Records Stored
Auto sync when online
GPRS
Connectivity
Built-in antenna module
24V DC
Power Input
Wide 9–36V range
Online
Reports
Server-based dashboards
Specifications
GPRS Module — Payload-T
Designed for tipper and dumper fleets that need real-time visibility of load and trip counts. Data is buffered onboard and pushed automatically to the cloud when the network is available.
16-bit CPU with memory
RS-232 communication to connect Payload-T
GPRS module with built-in antenna
Stores up to 5000 data records from Payload-T
Automatically transmits data once server connection is established
Synchronized data transfer with positive feedback
Server-based software for report generation
Power input 24V DC (wide input range 9–36V)
Overall dimensions: 216mm (L) × 95mm (B) × 96mm (H)
Rugged construction using military grade connectors
Online Reporting
Payload Monitoring System
View every vehicle's cumulative trips, loads, and overload status from the cloud dashboard. Data syncs automatically from the field module with positive feedback to avoid duplicates.
Synchronized, acknowledgement-based upload
Server-resident history for audits
Accessible from any PC with login
Works even after intermittent network
